Spianatrice erfurt quarta 2100mm 13 rulli diametro 140mm codice prodotto: 22460
scorri le foto orizzontalmente Dati tecnici:
Macchina consigliata
Prodotto perfetto
Spianatrice erfurt quarta 2100mm13 rulli / 13 rolls
diametro 140mm / diameter 140 mm
anno 1974 / year 1974
spessore 4mm/10mm / thickness 4/10 mm
4-HIGH PRECISION LEVELLER 2.100 X 10 (12)
Manufacturer: WMW-Erfurt (Germany)
Plate thickness: 4,0-10,0 mm (S325JR) 12,0 (S235JR)
Plate witdh max: 2.050 mm
N. of work rolls: 13
Diameter of work rolls: 140 mm, Width: 2.120 mm
N. of backup up rolls : 30, diam. 150 width 300 mm
Tilting (entry/exit) movement by electric motor.
Screwdown movement by electric motor.
Gearbox ratio: 1 / 28,6
Machine weight: Kg. 28.500
Main motor: DC, P=65 kW (Original, NOT INCLUDED)
Working speed : 15 m/’
Lubrication system: oil pump for gearbox, Grease pump on work rolls bearings.
Present condition: Good
Excluding: main motor, electric cabinet, electric on board line, switchboard.
Delivery: Ex Works (Incoterms 2020) loaded in container.
Delivery time: ready
Payment: 30% at the order, balance at the delivery.
